Nr.61-Leģēts 400 UNS N04400 EN 2.4360 Monel 400 skrūve

Specifikācijas

Alloy 400 UNS N04400 EN 2.4360 Monel 400 screw

1. Prompt & Professional Response.

2. Competitive & Credible Price.

3. High Quality & Fast Delivery.

4. Customized Service--(Produced according to customer's drawing or sample).

Partial order records of related products for your reference

Monel 400 fastener screw Exported to United Arab Emirates.

NO.	DESCRIPTION	QTY	Standarta
1	Monel 400 hex cap screw 3/4”-UNCx120mm	300PCS	ASME B18.2.1

Monel 400 hexagon head bolts c/w nuts Exported to Kerea

NO.	DESCRIPTION	QTY
1	Monel 400 hexagon head bolts c/w nuts DIN933/934, M12x45	1500set

Brief introduction of the material

Alloy 400 UNS N04400 EN 2.4360 Monel 400

A. Alloy 400 UNS N04400 EN 2.4360 Monel 400 Overview

Monel 400 is a nickel-copper alloy (about 67% Ni –23% Cu) that is resistant to sea water and steam at high

temperatures as well as to salt and caustic solutions. Characteristics:

1) Resistant to seawater and steam at high temperatures

2) Excellent resistance to rapidly flowing brackish water or seawater

3) Excellent resistance to stress corrosion cracking in most freshwaters

4) Particularly resistant to hydrochloric and hydrofluoric acids when they are de-aerated

5) Offers some resistance to hydrochloric and sulfuric acids at modest temperatures and concentrations, but

is seldom the material of choice for these acids

6) Excellent resistance to neutral and alkaline salt

7) Resistance to chloride induced stress corrosion cracking

8) Good mechanical properties from sub-zero temperatures up to 1020° F

9) High resistance to alkalis

Pielietojumi:

1) Marine engineering

2) Chemical and hydrocarbon processing equipment

3) Gasoline and freshwater tanks

4) Crude petroleum stills

5) De-aerating heaters

6) Boiler feed water heaters and other heat exchangers

7) Valves, pumps, shafts, fittings, and fasteners

8) Industrial heat exchangers

9) Chlorinated solvents

10) Crude oil distillation towers

B.Chemical Composition, %

C	Mn	S	Si	Ni	Cu	Fe
.30 max	2.00 max	.024 max	Ne vairāk kā .50	63.0 min	28.0-34.0	2.50 max

C. Mechanical Properties

Atlaidināta materiāla tipiskās istabas temperatūras stiepes īpašības

Produkta forma	Stāvoklis	Stiepes (ksi)	.2% raža (ksi)	Pagarinājums (%)	Cietība (HRB)
Stienis un bārs	Atkausēts	75-90	25-50	60-35	60-80
Stienis un bārs	Auksti vilkta Stress Relieved	84-120	55-100	40-22	85-20 HRC
Plāksne	Atkausēts	70-85	28-50	50-35	60-76
Lapa	Atkausēts	70-85	30-45	45-35	65-80
Tube & Pipe Seamless	Atkausēts	70-85	25-45	50-35	75 max *
